DESCRIPTION
The LC/APC to LC/APC 6-Core Compact Fiber Optic Adapter is designed to meet the needs of modern high-density optical networks. This adapter delivers reliable optical performance with precise alignment and low insertion loss. Its compact form factor makes it ideal for space-constrained applications, such as data centers and FTTH installations.
Engineered for LC/APC connections, this adapter ensures minimal signal degradation and high return loss, supporting seamless optical communication across diverse applications.
- Compact & Efficient: Space-saving design ensures compatibility with dense cabling environments.
- Ceramic Alignment Sleeves: Provides exceptional alignment precision, reducing optical losses.
- Durable Construction: High-quality materials enhance performance and withstand repeated use.
- 6-Core Configuration: Tailored for applications requiring mid-range fiber capacity.
| Parameter | Details |
| Connection Type | LC/APC to LC/APC |
| Fiber Count | 6 cores |
| Structure | Compact |
| Alignment Sleeve Material | Ceramic |
| Insertion Loss | ≤0.2 dB |
| Return Loss | ≥50 dB |
| Operating Temperature | -40°C to +75°C |
| Material | High-quality plastic and metal |
- Telecom Networks: Ensures stable and reliable connectivity for high-capacity systems.
- Data Centers: Provides efficient connection solutions for high-density fiber infrastructures.
- FTTH Deployments: Supports smooth optical terminations in residential or commercial environments.
- Optical Testing: Ensures precise and reliable connections for testing equipment.
This 6-core adapter meets international optical standards and integrates seamlessly with LC/APC connectors. Its lightweight and compact structure allows for flexible installation, particularly in space-constrained areas.
Q1: What makes the 6-core adapter unique?
It integrates six LC/APC ports in one compact housing, maximizing panel density while maintaining stable optical performance.
Q2: Is it only available in APC polish?
Yes. The LC/APC version provides superior return loss (≥ 60 dB), ideal for high-precision telecom and FTTH applications.
Q3: How is it different from standard duplex adapters?
While duplex adapters hold two fibers, this 6-core model supports six connections in a single module, saving 70% space.
Q4: What materials are used in construction?
It uses a durable PBT housing and zirconia ceramic alignment sleeves for excellent repeatability and thermal stability.
Q5: Can this adapter be customized in color or configuration?
Yes. Green is standard for APC, but other colors or panel mounting options can be customized upon request.
Q6: How is the adapter tested before delivery?
Each port undergoes 100% IL/RL and mechanical durability testing (500+ mating cycles) before packaging.
Q7: Where is it typically used?
Mainly in high-density distribution frames, optical modules, and outdoor telecom enclosures requiring compact APC connectivity.
