DESCRIPTION
The 96 Port 1U MPO/MTP to LC Modular Patch Panel is built for high-density applications where flexibility, fast deployment, and professional cable management are essential. Designed for use in data centers and telecom rooms, this panel integrates up to 4 modular cassettes to offer up to 96 LC fiber connections in a compact 1U height. The front houses LC duplex adapters while the rear accepts 8 MPO/MTP trunk connectors.
This patch panel enables ultra-efficient network organization, minimizes signal loss, and speeds up network rollouts — all while being future-ready for system upgrades.
Product Specifications
| Item | Details |
| Panel Capacity | 96 LC Ports (via 4x MPO/MTP-LC Duplex Cassettes) |
| Rack Compatibility | 19″/23″ Standard Rack Mountable |
| Material | Cold-Rolled Steel with Electrostatic Coating |
| Color | Black |
| Dimensions | 465mm × 240mm × 44mm (1U Height) |
| Cassette Support | 4 × Modular Plastic MPO/MTP-LC Duplex Cassette |
| Adapter Type (Front) | LC Duplex |
| Connector Type (Rear) | 8 × MPO/MTP Female |
| Fiber Type | Singlemode (OS2) and Multimode (OM3/OM4) |
| Operating Environment | Indoor, Data Center, Server Room |
| Cable Management | Rear cable manager integrated |
| Mounting Style | Front and Rear Mounting Options |
Feature Details
- Fast Deployment: Pre-terminated cassettes eliminate on-site termination, ensuring reliability
- High Density: Houses up to 96 fibers in just 1U, perfect for space-constrained environments
- Flexibility: Mix singlemode and multimode cassettes based on network segment needs
- Easy Maintenance: Tool-less cassette insertion/extraction simplifies changes and replacements
- Cable Integrity: Internal routing paths and cable clamps reduce risk of microbends or breakage
Application Details
- Supports cross-connect, interconnect, or hybrid network architecture
- Reduces patching errors and simplifies troubleshooting in multi-rack environments
- Can be deployed with MTP/MPO trunk cables and LC breakout patch cords
- Ideal for structured cabling deployments following TIA-942 and EN 50173-5 standard
FAQ
Q1: What is the capacity of this 1U MPO/MTP to LC Patch Panel?
A1: It holds up to four MPO/MTP-LC duplex cassettes, providing a total of 96 LC fiber connections in a 1U height.
Q2: What environments is this patch panel designed for?
A2: It’s ideal for high-density data centers, telecom networks, and structured cabling systems requiring quick deployment and flexible upgrades.
Q3: What are the rear and front connector types?
A3: The rear supports 8 MPO/MTP female trunk connectors, and the front provides 96 LC duplex adapter ports.
Q4: What fiber types are supported?
A4: Both Singlemode (OS2) and Multimode (OM3/OM4) fibers are compatible, depending on the cassette configuration.
Q5: What material and finish are used for the panel?
A5: Made from cold-rolled steel with an electrostatic powder-coated finish for superior durability and corrosion resistance.
Q6: How is cable management handled?
A6: The panel includes an integrated rear cable manager that secures trunk cables and maintains bend radius for optimal signal integrity.
Q7: Can this panel support modular upgrades?
A7: Yes — its modular design allows mixing of different fiber types and easy cassette replacement for network reconfiguration.
Q8: What standards does it comply with?
A8: Fully compliant with TIA-942 and EN 50173-5 structured cabling standards, ensuring reliability in professional fiber installations.
