DESCRIPTION
The FHD 1U 96F MPO/MTP-LC Standard Fixed Rack-Mount Patch Panel is a high-density, durable solution for managing fiber optic terminations and connections. Specifically designed for data centers and telecom networks, this patch panel supports up to 96 fibers, optimizing rack space while minimizing floor space.
Its versatile design accommodates 4 MPO/MTP-LC/SC cassette modules or fiber adapter panels, providing flexibility for various fiber management applications. Constructed from cold-rolled steel, the panel ensures durability, while its compact 1U height makes it suitable for space-constrained environments.
Feature Details
- High-Density Fiber Termination
- Holds up to 96 fibers for maximum connectivity.
- Supports 4 cassette modules for streamlined fiber management.
- Standard Rack Mount Compatibility
- Designed for EIA 19″ rack-mount cabinets, ensuring seamless integration with industry-standard racks.
- Robust CRS Construction
- Cold-rolled steel construction enhances durability and provides long-term reliability in demanding environments.
- Flexible Configuration Options
- Compatible with MPO/MTP-LC/SC cassettes and fiber adapter panels, making it suitable for various network setups.
- Efficient Cable Management
- Simplifies cable routing and reduces clutter, improving maintenance and system organization.
Product Specifications
| Parameter | Specification |
| Product Name | FHD 1U 96F MPO/MTP-LC Standard Fixed Rack-Mount Patch Panel |
| Enclosure Type | 19″ Rack Mountable |
| Fiber Count | Max. 96 Fibers |
| Installation | Standard EIA 19″ Rack |
| Material | CRS (Cold Rolled Steel) |
| Compliant Standards | TIA/EIA-568-C.3 |
| Dimensions (HxWxD) | 1U x 481mm x 251.5mm |
Application Details
- Data Centers: Provides high-density fiber termination and patching for structured cabling systems.
- Telecom and Broadband Networks: Ensures efficient cable management and fiber distribution.
- LAN/WAN Infrastructure: Supports enterprise and business fiber networks requiring reliable connectivity.
- FTTH Central Offices: Centralizes fiber connections in fiber-to-the-home distribution points.
FAQ
Q1: What is the capacity of the FHD 1U 96F Patch Panel?
It supports up to 96 fibers using 4 modular MPO/MTP-LC or SC cassette modules, making it suitable for high-density fiber installations.
Q2: Is this panel compatible with standard rack systems?
Yes. It fits standard EIA 19″ rack-mount cabinets, ensuring seamless integration into data center and telecom infrastructures.
Q3: What fiber types can this panel support?
The enclosure supports Singlemode (OS2) and Multimode (OM3/OM4) fibers, adaptable to various data transmission and bandwidth requirements.
Q4: What materials are used for construction?
It’s made from CRS (cold-rolled steel) with an anti-corrosive powder coating, ensuring superior strength and long-term durability.
Q5: Can this panel be customized?
Yes. It can be configured with LC, SC, or MTP/MPO cassettes, and labeling or port marking can be customized upon request.
Q6: What are the common applications of this patch panel?
It’s widely used in data centers, telecom rooms, LAN/WAN infrastructures, enterprise networks, and FTTH central offices for organized fiber management.
Q7: How is cable management handled in this panel?
The design includes integrated routing paths that reduce clutter and maintain optimal bend radius, ensuring reliable optical performance.
Q8: What is the standard delivery and packaging format?
Standard models are typically in stock for fast delivery; each unit is securely packed with protective foam and accessories (screws, ties, glands).
