DESCRIPTION
High Quality and Cost-effective IP67 MPO/MTP Female OM3 Waterproof Fibers Optic Patch Cords
The ODVA MPO/MTP OM3 IP67 5.5mm Waterproof Fiber Patch Cable is designed to meet the demands of outdoor fiber optic connectivity. Built for FTTA, RRH, and industrial applications, this patch cable features an IP67-rated ODVA MPO/MTP connector that ensures robust resistance against environmental challenges such as water, dust, and extreme temperatures.
With its low insertion loss and high return loss, the patch cable supports high-performance optical transmission in harsh conditions. The aqua-colored OM3 fiber provides excellent bandwidth capabilities, making it suitable for telecom, CATV, and other outdoor applications requiring reliability and durability.
Engineering Suitability & Selection Boundaries
When This Product Is the Right Choice
FTTA feeder deployments where MPO/MTP interfaces are used to connect RRHs and base station equipment in outdoor environments.
Scenarios requiring high-density fiber connectivity combined with environmental sealing for 3G, 4G, and 5G infrastructure.
Outdoor structured cabling installations involving horizontal or vertical routing, where bundled fiber connections simplify deployment.
Industrial outdoor applications where IP67 protection is necessary to withstand moisture, dust, and corrosion over long-term operation.
When This Product May NOT Be Suitable
Indoor data center environments where standard MPO/MTP patch cords can be used without environmental sealing.
Deployments that require single-fiber or low-density connections, where MPO/MTP assemblies introduce unnecessary complexity.
Installations without MPO/MTP-compatible equipment, making multi-fiber interfaces impractical.
Common Selection Mistakes to Avoid
Treating an outdoor MPO/MTP cable as a direct substitute for indoor MPO/MTP patch cords, without considering sealing and deployment context.
Selecting MPO/MTP assemblies without evaluating actual fiber density and link architecture requirements.
Overlooking system-level compatibility, such as connector interface expectations and routing constraints in FTTA environments.
Feature Details
- IP67-Rated Protection
- Fully sealed circular design protects against water, dust, and debris ingress.
- Operates efficiently in temperatures ranging from -40°C to +75°C.
- High-Performance Transmission
- Standard MPO/MTP insertion loss ≤0.6dB; Elite MPO/MTP ≤0.35dB.
- High return loss reduces signal degradation, ensuring stable connectivity.
- Versatile Cable and Connector Options
- Available with 4.8mm, 5.0mm, 5.5mm, and 7.0mm cable diameters for diverse setups.
- Supports duplex OM3 fiber for efficient data transfer over long distances.
- Customizable and Reliable
- Options for UPC or APC polishing tailored to your application needs.
- Ensures long-lasting durability with LSZH jacket material for fire safety compliance.
Product Specifications
| Parameter | Specification |
| Connector Type | ODVA MPO/MTP |
| Fiber Mode | OM3 |
| Polish | UPC to UPC |
| Fiber Type | 8F/12F/24F |
| Jacket Material | LSZH |
| Jacket Outer Diameter | 5.5mm |
| Insertion Loss (MPO) | ≤0.75dB |
| Insertion Loss (Elite MPO) | ≤0.35dB |
| Wavelength | 850nm/1300nm |
| Operating Temperature | -40°C to +75°C |
| Storage Temperature | -45°C to +85°C |
Application Details
- FTTA and RRH Deployments: Provides secure and high-performance fiber connections for remote radio heads in telecom networks.
- Industrial Networks: Delivers stable connectivity in oil fields, mining sites, and other harsh outdoor environments.
- Structured Cabling: Suitable for horizontal and vertical outdoor cabling in data centers and industrial setups
FAQ
Q1: What is the advantage of the ODVA MPO/MTP connector?
It is IP67-rated, offering waterproof and dustproof protection for outdoor applications like FTTA and RRH.
Q2: Why use OM3 fiber?
OM3 multimode fiber supports high-speed transmission (10G, 40G, 100G) over short-to-medium distances, making it cost-effective for telecom and CATV.
Q3: Can this cable handle harsh environments?
Yes. The 5.5 mm jacket and IP67 housing ensure resistance to water, dust, and temperature changes.
Q4: What are the optical specs?
Insertion loss ≤0.35 dB (elite) or ≤0.75 dB (standard); return loss ≥20 dB. All assemblies are 100% tested.
Q5: Is customization available?
Yes. Length, jacket type (LSZH, PVC, OFNP), labeling, and color can be customized.
Q6: What are the main applications?
FTTA, RRH, telecom networks, CATV, and outdoor industrial connections.
Q7: What is the delivery time?
Standard lengths are often in stock; custom versions usually take 5–10 working days.
